POWER9 EV CHARGING EQUIPMENT
EV Charging Station Manufacturer in India – Power9 AC & DC Chargers
Different charging applications require different combinations of charging speed, electrical capacity and user access.
Power9 is an EV charging station manufacturer in India offering AC and DC EV charging equipment for workplaces, fleets, commercial properties, apartments and other managed charging environments. Explore our AC and DC charger range, compare specifications, protection features and connected-charging capabilities, and select a charger based on your project requirements.
Power9 EV Charging Equipment
As an EV charging equipment manufacturer, Power9 develops charger configurations for different charging speeds, installation environments and project requirements. The current range includes AC charging and DC fast-charging solutions with connected-management and protection features.
Power9 AC Type 2 Dual Gun EV Charger
11.5 kW × 2 | 23 kW Total System Output
Model: P9-AC22D
The Power9 AC Type 2 Dual Gun EV Charger is designed for applications where vehicles remain parked for longer periods and managed AC charging is suitable. It can be considered for workplace, apartment, commercial and destination-charging environments depending on project requirements.
| Key Specifications | Power9 AC Dual Gun Charger |
|---|---|
| Model | P9-AC22D |
| Charger Type | AC |
| Number of Guns | 2 |
| Output Per Gun | 11.5 kW |
| Total System Output | 23 kW |
| Output Voltage | 230 V AC |
| Connector | IEC 62196-2 Type 2 |
| Cable | 5 m standard / 7 m optional |
| Input | 230 V AC, single phase |
| Frequency | 50 / 60 Hz |
| Efficiency | >94% |
| Display | 4.3" TFT LCD colour |
| Network | 4G LTE / Wi-Fi / LAN |
| OCPP | 2.0.1 with 1.6J backward compatibility |
| Enclosure | IP54 |
| Impact Rating | IK08 |
| Mounting | Floor-standing |
| Dimensions | 400 × 250 × 1200 mm |
| Weight | 28 kg |
Charge Two Compatible EVs Simultaneously
One of the defining features of the P9-AC22D is its dual-gun configuration. Instead of allocating a separate charger cabinet to each parking position, the system provides two Type 2 charging outputs from one floor-standing unit. Each output is specified for 11.5 kW, enabling 23 kW combined simultaneous charging. This can be useful in charging environments where vehicles have relatively long parking durations but more than one user needs charger access.
Smart User Access
The charger specification supports several user-authentication methods: RFID, NFC, QR code, App-based authentication It can locally store multiple RFID credentials, helping support managed charging environments with multiple authorised users.
Connected Charging
The AC charger includes: OCPP 2.0.1, Backward OCPP 1.6J support, 4G LTE, Wi-Fi, LAN, Remote start/stop, OTA updates These capabilities enable the charger to communicate with compatible charging-management infrastructure.
Charging Information at a Glance
A built-in 4.3-inch colour display presents session and charging information. Depending on available data, the display can show: Power, Voltage, Current, Frequency, Energy consumed, Charging time, User information, Charger status Fault information
Dynamic Load Management
The AC charger specification includes dynamic load-management functionality. For sites with multiple electrical loads, controlled charging can be an important part of making better use of available electrical capacity. The final load-management architecture should always be designed according to the site’s actual electrical system.
AC EV Charger Protection & Outdoor Installation
Power9 AC charging equipment includes model-specific protection and installation features designed for suitable indoor and outdoor operating environments.
Over-voltage protection
Under-voltage protection
Over-current protection
Over-temperature protection
Short-circuit protection
Earth-leakage protection
Type 2 surge protection
* An optional emergency-stop configuration is also listed.
Where Can the Power9 AC Charger Be Used?
Workplaces
Longer employee parking periods can make AC charging practical.
Apartments & Residential Parking
The charger can be evaluated for planned shared charging environments where the electrical infrastructure and vehicle compatibility support it.
Commercial Properties
Two charging outputs can help provide charging access to more than one vehicle.
Destination Charging
Suitable charging locations may include places where vehicles remain parked for extended periods.
Power9 20/30 kW DC Fast Charger
Selectable 20 kW / 30 kW DC Charging
Model: P9-DC30S
The Power9 DC Fast Charger is designed for applications where faster energy delivery is required compared with conventional AC charging. Suitable deployment depends on the vehicle, site electrical capacity, expected charging demand and project configuration.
| Key Specifications | Power9 P9-DC30S |
|---|---|
| Charger Type | DC Fast Charger |
| Output Power | 20 kW / 30 kW selectable |
| Output Voltage | 200–1000 V DC |
| Maximum Output Current | 125 A |
| Input Voltage | 380–415 V AC |
| Input | Three-phase |
| Frequency | 50 / 60 Hz |
| Number of Guns | 1 |
| Cable | 5 m standard / 7 m optional |
| Efficiency | >93% at full load |
| Display | 7" TFT colour touchscreen |
| OCPP | 2.0.1 with 1.6J backward compatibility |
| Network | 4G LTE / Wi-Fi / LAN |
| Enclosure | IP54 |
| Impact Rating | IK10 |
| Mounting | Floor-standing |
| Dimensions | 560 × 260 × 1200 mm |
| Weight | 55 kg at 20 kW / 65 kg at 30 kW |
Select 20 kW or 30 kW Output
The P9-AC22D supports 20 kW and 30 kW operating configurations. This gives project planners another factor to consider when matching charging capacity with the vehicle, electrical infrastructure and operational charging window. Higher charger capacity should only be selected when the vehicle and site can make practical use of it.
Wide DC Output Range
The charger operates across a specified 200–1000 V DC output range with maximum output current of 125 A. Actual vehicle charging performance depends on the vehicle’s supported charging characteristics, battery state, temperature and charging curve.
7-Inch Touchscreen Interface
The integrated 7-inch colour touchscreen can display charging-session information including: Charging power, Voltage, Current, Vehicle state of charge where available, Session energy, Elapsed time, Charging cost, User identification, Fault information,Charger status.
Built for Managed Charging Environments
Power9 DC charging solutions can integrate with managed charging environments through supported communication, monitoring and access-control functionality. Available features depend on charger configuration and project requirements.
Dynamic Load Management
Helps support controlled electrical demand.
Charging Scheduling
Can support time-based charging strategies.
Fleet Management
The specification includes multi-site and multi-charger dashboard capability.
Flexible Authentication
RFID, NFC, QR and app-based methods are listed.
Charging Management
Supported billing configurations include energy, time and flat rate models. Commercial deployment and payment configuration should be confirmed according to the actual charging-management platform used.
EV Charging Equipment Protection & Safety
Protection features are an important consideration when evaluating EV charging station suppliers. Power9 chargers include model-specific electrical and operational protection features intended for their applicable installation and charging environments.
- Specified protection includes:
- Over-voltage protection
- Under-voltage protection
- Over-current protection
- Over-temperature protection
- Short-circuit protection
- Integrated insulation monitoring
- Earth-leakage protection
- Type 2 surge protection
- Emergency-stop button
- The enclosure is rated IP54, while the cabinet has an IK10 impact rating.
Recommended EV Charging Environments
Power9 AC and DC chargers can be evaluated for different environments depending on power availability, vehicle dwell time, daily charging demand and site requirements.
Then list only genuine application types:
- workplace charging
- fleet charging
- commercial charging
- apartment/shared parking
- destination charging
Final product selection should still be based on vehicle compatibility, site conditions and project charging requirements.
What to Look for in an EV Charging Station Manufacturer
When evaluating charging station manufacturers in India, consider more than charger power alone. Review the product specifications, protection features, connected-management capabilities, technical documentation, installation requirements and intended application.
Power9 provides AC and DC charging equipment with product-specific specifications and project-oriented configuration options for different EV charging environments.
Frequently Asked Questions About EV Charging Stations
Is Power9 an EV charging station manufacturer in India?
Power9 is an EV charging brand of Global Futuretech Private Limited, offering AC and DC EV charging equipment for different residential, commercial, workplace and fleet applications.
What EV chargers does Power9 offer?
Power9 offers AC charging and DC fast-charging solutions with model-specific power ratings, communication, access-control and protection features.
What is the difference between AC and DC EV chargers?
AC chargers are commonly suited to locations where vehicles remain parked for longer periods, while DC chargers are generally used where faster charging is required. The suitable charger depends on the vehicle, site infrastructure and intended application.
Does Power9 provide connected EV charging?
Selected Power9 chargers support connected functionality such as communication, charger monitoring and access-control features depending on the model and configuration.
Can Power9 chargers be installed outdoors?
Both current charger specifications carry an IP54 enclosure rating. Final installation should still follow the manufacturer’s installation instructions, electrical requirements and site-specific environmental assessment.
Can Power9 chargers be used for commercial projects?
Power9 AC and DC EV chargers can be evaluated for workplace, fleet, commercial, apartment and destination-charging projects depending on the electrical and operational requirements.
Need Help Choosing the Right EV Charger?
Tell us about your site, expected vehicle usage, available power and charging requirements. Power9 can help you evaluate whether an AC charger, DC charger or another configuration is suitable for your project.
